TSA-103 Products Information

Application and specific quality of Automatic Ejecting Oven



The main application of Automatic Ejecting Oven is to develop a product with the condition of very short time of heat flow curing (10~50 sec) for coil coating(PCM), metallic plate coating, can coating and ink industries.



It has a feature of an easy control of wind velocity according to the size and thickness of test piece. Also, the hot wind sprays on the cover of the test piece directly. So, it can be tested in the high-thermal condition and uniform temperature as the most similar to the condition of heat flow time of coil coating line. In the continual testing on several test pieces, it is so precise that the discrepancy of color & gloss was hardly generated.





In case of Automatic Ejecting Oven, we remove the large door as in a Box type Oven and make a small lid to input test pieces in order to minimize the heat leakage. Therefore, it can meet the perfect color and gloss which is the most similar to the condition of coil coating line even under the condition of short time of heat flow curing (10~50 sec.). As a result, it has been approved as an excellent oven by renowned global paint makers like Akzo, PPG, Valspar, SIGMA and many others in Korea, Japan and China.

T S A - 1 0 3

SKU/항목 번호:  000000

Specifications 3  T S A - 1 0 3

문의처:

전화: 82-2 -2672-5228

팩스: 82-2-2672-5238

전자 메일: taesung-tech@hanmail.net

TAE SUNG E.N.G., SEOUL, KOREA



19. Relay for heater : contact-less relay

20. Wind velocity controller : wind velocity adjusting

Range ; 1 ∼ 5m(basically 3m)

21. Wind volume : 25㎥ / Min

22. Mobility : by free wheel with stopper - 4pieces

23. Safety devices :

1) Damper for safety air taking in ; Adjust by damper

when the temperature goes up

2) Overheat protection device ; digital setting and digital display.

Range ; 0 ～ 550℃

3) Alarm buzzer for abnormal conditions ; alarming flicker lamp with buzzer

4) Safety door (at upper part of ceiling) ; opens on explosion and cuts all

power supply

5) Blower motor ; 1.5kw motor with increased safety (inverter motor)

6) Motor protection ; thermal relay provided for overheat of motor

7) Locking device for tray ; provided

24. External thermometer : The measurement for speed of the temperature rise.

25. Insulation : Ceramic H/B & ceramic fiber

26. Weight : app 800Kg

* The information and specifications contained in this leaflet are subject to

without notice.

1. Model : T S A - 1 0 3

2. Maximum working temperature : 540℃

3. Ordinary running temperature : 100 ~ 500℃

4. Warming up : ambient to 400℃ / within 1 hour (in spring and autumn time)

5. Accuracy of temperature display : ±1.0℃

6. Temperature distribution n( ambient) : ±1.0℃

7. Size of test piece : 250mm x 330mm (at maximum)

8. Inlet for test piece loading : one

9. Power source : 3Ø, 220V or 380V, 440V

10. Electric capacity : 15.2kw

11. Dimensions : W1,340mm x H1,860mm x D990mm

12. Material of inner surface of baking room : SUS 304 5.0T

13. Test piece loading tray : Single tray - SUS 304

14. Tray up and down driving device : electro-motive

15. Circulating blower : Double sirocco fan with 232mm

Diameter - made of SUS 304

16. Temperature controller : digital setting and digital display

Range ; 0 ∼ 550℃

17. Timer : digital setting and digital display

Range ; 0 ~ 999.9 seconds

18. Heater : Sheathed heater with heat radiation fin

Capacity ; 13.5kw (1.5kw x 9 pieces)

D-306 Guro Commercial  Bldg., 54Gil 4, Guro-Gu, Seoul 152-866 Korea

Tel: 82-2 -2672-5228

Fax: 82-2-2672-5238

e-Mail: taesung-tech@hanmail.net

     - CE Certificate -

   EN ISO12100-1, 2 ,

   EN ISO14121-1

   EN 60204-1



      - EN Certificate -

   EN ISO 12100:2010

   EN 1539:2009



 + 폭발방지 안전인증
