Application and specific quality of Automatic Ejecting Oven
The main application of Automatic Ejecting Oven is to develop a product with the condition of very short time of heat flow curing (10~50 sec) for coil coating(PCM), metallic plate coating, can coating and ink industries.
It has a feature of an easy control of wind velocity according to the size and thickness of test piece. Also, the hot wind sprays on the cover of the test piece directly. So, it can be tested in the high-thermal condition and uniform temperature as the most similar to the condition of heat flow time of coil coating line. In the continual testing on several test pieces, it is so precise that the discrepancy of color & gloss was hardly generated.
In case of Automatic Ejecting Oven, we remove the large door as in a Box type Oven and make a small lid to input test pieces in order to minimize the heat leakage. Therefore, it can meet the perfect color and gloss which is the most similar to the condition of coil coating line even under the condition of short time of heat flow curing (10~50 sec.). As a result, it has been approved as an excellent oven by renowned global paint makers like Akzo, PPG, Valspar, SIGMA and many others in Korea, Japan and China.
|
|
T S A - 1 0 2 |
|
SKU/Ç׸ñ ¹øÈ£: 000000 |
|
¹®ÀÇó: |
|
ÀüÈ: 82-2 -2672-5228 Æѽº: 82-2-2672-5238 ÀüÀÚ ¸ÞÀÏ: taesung-tech@hanmail.net |
|
TAE SUNG E.N.G., SEOUL, KOREA |
|
19. Relay for heater : contact-less relay 20. Wind velocity controller : wind velocity adjusting Range ; 1 ¡ 5m(basically 3m) 21. Wind volume : 25§© / Min 22. Mobility : by free wheel with stopper - 4pieces 23. Safety devices : 1) Damper for safety air taking in ; Adjust by damper When the temperature goes up 2) Overheat protection device ; digital setting and digital display. Range ; 0 ~ 450¡É 3) Alarm buzzer for abnormal conditions ; alarming flicker lamp with buzzer 4) Safety door (at upper part of ceiling) ; opens on explosion and cuts all power supply 5) Blower motor ; 1.5kw motor with increased safety( Inverter motor) 6) Motor protection ; thermal relay provided for overheat of motor 7) Locking device for tray ; provided 24. External thermometer : The measurement for speed of the temperature rise. 25. Insulation : All ceramic fiber 26. Weight : app 800Kg * The information and specifications contained in this leaflet are subject to without notice. |
|
1. Model : T S A - 1 0 2 2. Maximum working temperature : 450¡É 3. Ordinary running temperature : 50 ¡ 400¡É 4. Warming up : ambient to 300¡É / within 1 hour (in spring and autumn time) 5. Accuracy of temperature display : ¡¾1.0¡É 6. Temperature distribution(ambient) : ¡¾1.0¡É 7. Size of test piece : 250mm x 330mm (at maximum) 8. Inlet for test piece loading : one 9. Power source : 3¨ª, 220V or 380V, 440V 10. Electric capacity : 13.4Kw 11. Dimensions : W1,340mm x H1,860mm x D990mm 12. Material of inner surface of baking room : SUS 304 4.0T 13. Test piece loading tray : Single tray - SUS 304 14. Tray up and down driving device : electro-motive 15. Circulating blower : Double sirocco fan with 232mm Diameter - made of SUS 304 16. Temperature controller : digital setting and digital display Range ; 0 ~ 450¡É 17. Timer : digital setting and digital display Range ; 0 ¡ 999.9 seconds 18. Heater : Sheathed heater with heat radiation fin Capacity : 11.7kw (1.3kw x 9 pieces) |
|
Specifications 2 T S A - 1 0 2 |
|
D-306 Guro Commercial Bldg., 54Gil 4, Guro-Gu, Seoul 152-866 Korea Tel: 82-2 -2672-5228 Fax: 82-2-2672-5238 e-Mail: taesung-tech@hanmail.net |
|
- CE Certificate - EN ISO12100-1, 2 , EN ISO14121-1 EN 60204-1
- EN Certificate - EN ISO 12100:2010 EN 1539:2009
